Model TOP14K-T TOP16K-T |
||
|
Battery Capacity(wh) |
14336 |
16076 |
|
Number of cells |
1P8S*2 |
|
|
Cell Type |
LFP |
|
|
Nominal Voltage (V) |
51.2 |
|
|
Operating Voltage Range (V) |
46.4~57.6 |
|
|
Max.Charge /Discharge Current (A) |
200 |
|
|
Continuous Charging/Discharging Current (A) |
200 |
|
|
Max.Power（W） |
10240 10240 |
|
|
Dimension (H*W*D mm) |
1169.5*640*197 |
|
|
Weight（KG） |
150 158 |
|
|
Operating Temperature Range (℃) |
-20-50 |
|
|
Temperature.Control |
Auto Heat pump |
|
|
Coolant |
ethylene glycol C2H4(OH)2 |
|
|
Charge and Discharge Efficiency |
96.1% |
|
|
Max.Number of Parallel |
15 |
|
|
Communication |
CAN,RS485,WIFI |
|
|
DOD |
100% |
|
|
Ingress Protection Rating |
IP65 |
|
|
Installation |
Floor Mount |
|
|
Relative Humidity |
≤95%rh |
|
|
Humidity of storage environment |
≤95%rh |
|
|
Max. Operating Altitude (m) |
≤3000m |
|
|
Storage Temperature |
≤25℃ , 12 months ；≤35℃ , 6 months ；≤45℃ , 3 months |
|
|
Certification |
TUV,RoHS,MSDS,UN38.3,IEC62619,CE |
|
